Patch Cord UTP RJ45, Cat.5e, 0.5m
Patch Cord UTP RJ45, Cat.5e, 0.5m
Patch Cord UTP RJ45, Cat.5e, 0.5m
Patch Cord UTP RJ45, Cat.5e, 0.5m
Patch Cord UTP RJ45, Cat.5e, 0.5m

Patch Cord UTP RJ45, Cat.5e, 0.5m

The unshielded UTP 5E class 0.5m long unshielded UTP switch wire consists of a 4-pair 0.5m long multi-core cable, compressed by RJ45/8P8C connectors according to T568-B. The patch wire complies with ISO/IEC 11801, EN 50173, and TIA/EIA-568 standards.

Share:

The unshielded UTP 5E class 0.5m long unshielded UTP switch wire consists of a 4-pair 0.5m long multi-core cable, compressed by RJ45/8P8C connectors according to T568-B. The patch wire complies with ISO/IEC 11801, EN 50173, and TIA/EIA-568 standards.

Specification

ParameterValue
TypeUTP
Qty pair4
Bandwidth, MHz100
Conductor material100% new oxygen free copper
Conductor diameter, mm0.48
Insulation conductor diameter, mm0.88±0.03
Shell materialPVC
Outer diameter of shell, mm5±0.2
ColorGrey
Temperature range, °СStorage -20...+75, Operation -20...+75
PackageIndependent packaging
Connector TypeRJ45
Test FlukeYes

XI’AN OPT Communication Co.,Ltd  is one of the largest and reliable manufacturers and suppliers of copper system with rich experience in China. OPT has invested a large amount of resources in product R&D, quality control, professional technical support in networking solutions, to provide customers with higher-performance and the most cost-effective products. We can customized as your requirement.Also, free sample is also available if necessary.
