Ethernet to fiber converter is designed with a switch controller and buffer memory that connects two types segments operation smoothly. The media converter fiber to ethernet can be used as standalone type or as card type to the 2U 19'' converter rack-mount chassis for centralized
power management.
Data Rate: 10/100/1000Mbps.
Fiber Type: 20/40/60/80/100KM for Single mode.
Optic Connector: SC(optional)/ST/FC
Share:
1. Built-in efficient exchange kernel, Broadcasting filtration function,
fIow control, CRC error check.
2.Supports SPANNING TREE to conduct fault-tolerant network.
3.Supports 10/100/1000Mbps full/half duplex self-adaptive transmission and auto-negotiations ,easy upgrades.
4.Max.transmission distance can be 100km.
5.External power .
6.Standalone type can be installed into 14sIot 2U Rack;
7.Hot-swap ,High reliability.
8.Cache capacity: IM Bits.
9.Built-in MAC address butter space : 1K.
Specification
Media converter fiber to ethernet 2x 10/100/1000/Base-T RJ45 to 2x 1000 Base Dual fiber 1310 nm
| Items | 10/100/1000M Dual fiber Media Converter |
| Rate | 10/100/1000Mbps |
| Protocol supported | IEEE802.3/IEEE802.3U etc. |
| Connector | 2x 10/100/1000/Base-T RJ45 to 2x10/ 100/1000 Base fiber port |
| Fiber type | Dual fiber |
| Optic mode | Single model/ Multimode |
| Transmission mode | half / full duplex |
| Ethernet interface | RJ-45 |
| Optic interface | SC/FC/ST |
| Optic wavelength | 850nm, 1310nm, 1550nm |
| BER | < 1/1000000000 |
| MTBF | 3 years |
| POWER | 2.5W |
| Power supply | AC220V/0.5A, DC48V/0.5A, DC5V/1A |
| Working temperature | normal 0~50℃ or industrial -40~85℃ |
| Working humidity | 5%-95% |
| Storage temperature | -40℃~70℃ |
| Storage humidity | 5%~95%(no-condensing) |
| Weight | 0.38KG |
| Dimensions | External: LxWxH 95 x 70x 26mm |
